300x3mm Duplex Dish Ends For Pressure Vessel Joggled Elliptical Head

Brand Name : GLM

Model Number : CAP

Certification : ASME, PED and GB

Place of Origin : China

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50000

Packaging Details : wooden box and iron shelf or as percustomers requirement

Head Code : joggled head

Technology : Hot pressing,cold pressing

Reduction ratio : about 10%

Certificate : ISO9001 ,ISO14001,OHSAS18001

Contact Now

**Special 300*3mm as a whole steel ball to form joggled head**

Description:

We are a leading Dished End Manufacturer in China. We have been offering an ample array of products that includes Fabricated Dish End, Single Piece Dished End, Duplex Material Dished End, 32mm Dished end, Dish End Elliptical Heads, Dished End Torispherical Heads and so on.

All our products are accessible in a variety of specifications, designs and dimensions. In addition to this, we have been providing the array in small as well as large volumes as per the requisites of the customers. Our products are offered in a range of formats with horizontal as well as vertical installation provision according to the needs of the clients.

Specifications:

Brand Name:	GLM
Diameter:	89mm--10000mm
Thickness:	2mm--300mm
Reduction Ratio:	about 10%
Material:	Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method:	Hot forming,cold forming
Surface Treatment:	Sand Blasting,Pickling,oil,discaling
Inspection:	UT,RT,MT,PT,TOFD.
Applicable Standard:	ASME ,PED and GB
Certificate:	ISO9001,ISO45001,OHSAS18001
Applications:	Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc.
Package:	Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product:	Available

joggled head Product Image

300x3mm Duplex Dish Ends For Pressure Vessel Joggled Elliptical Head

Company proflie

300x3mm Duplex Dish Ends For Pressure Vessel Joggled Elliptical Head

Our Advantages

300x3mm Duplex Dish Ends For Pressure Vessel Joggled Elliptical Head

Package Information

300x3mm Duplex Dish Ends For Pressure Vessel Joggled Elliptical Head
